4.5 Inch Lift Kit - Honda Pilot 2016-2022 - Passport 2019-2025 - Ridgeline 2017-2026 - Ridgeline 2006-2014 By HRG OFFROAD Beast Kit

Own the Biggest, Baddest Honda Ridgeline on the Trail

Want the most aggressive Ridgeline in town? Look no further. Our 4.5” (114mm) BEAST Lift Kit is the largest lift kit on the market, engineered to turn your Ridgeline into a true off-road monster. This world-first, 100% bolt-on system requires no welding and is designed to push your adventures further than ever before.

Why Choose the BEAST Lift Kit?

Unmatched Lift Height
At 4.5”, this is the tallest lift available—dramatically improving approach, breakover, and departure angles so you can confidently tackle tougher terrain.

Precision Engineered Geometry
Offset front spacers correct camber and caster for proper alignment, while subframe and engine drop spacers preserve critical suspension and axle geometry—all while maximizing ground clearance.

Built to Last
Every component is powder-coated for durability and corrosion resistance, and all hardware is zinc-plated grade 10.9 for maximum strength in harsh conditions.

Factory Ride Quality Retained
Enjoy the added capability without sacrificing the smooth, comfortable ride Honda is known for.

Expert Support
Our technical support team is available Monday–Friday to help every step of the way.

Kit Specifications

• Lift Height: 4.5” (114mm)
• Weight: 30 lbs
• Compatibility:
  2017–2025 Honda Ridgeline
  (LX, RTS, RTL, RTL-T, Black Edition, EX-L, LX-AS, Sport, RT, Touring, RTL-E, TrailSport)

What’s Included

• (2) Offset Front Lift Spacers
• (2) Rear Lift Spacers
• Full 2” Subframe Drop
• 2” Engine Drop
• Trailing Arm Spacers
• Brake Line Relocation Brackets
• Extended Exhaust Hangers
• All Required Hardware
• Detailed, Illustrated Instructions
• HRG T-Shirt

Installation Details

• Estimated Install Time: 7–8 hours
• Recommended Tire Sizes:
  • 265/60R18
  • 265/50R20
• Professional installation recommended

Running factory wheels? Pair this kit with our 1” billet wheel spacers, precision-machined specifically for the Honda Ridgeline.

Warranty

Lifetime Warranty on all lift kit components.
